Overview
High definition full motion video
(1920x1080).

Clear, concise, organized,
detailed and easy to understand.

Step by step instructions

1 hour 35 minutes total video run time.

Proven training curriculum.

This listing is for 1 DVD.

Why buy this training course?

Risk free. We offer a 14 days money back return policy! You will not find a seller that offers this return policy! We are confident that you will find this training course helpful and see it as a good value.
Give yourself a competitive edge in the job market by learning a new skill.
Increase your worth to your employer and move up the career ladder.
Make more money and live better. People with Allen Bradley software skills can earn over $100,000 per year.
Good value. An equivalent training course from Allen Bradley can cost over $1000.
Learn faster with a proven video curriculum. Research has shown that it is more efficient to learn from a video than from a book. "A picture is worth a thousand words."
We have 100% feedback. Our products have helped and satisfied many buyers.

Description:

The Allen Bradley RSLOGIX 500 Pro Training Course quickly and efficiently trains technicians and engineers on how to use Allen Bradley RSLOGIX 500 Pro software. The training course goes over the steps to setup, create, download, upload, test and troubleshoot PLC programs for Allen Bradley PLCs.
RSLOGIX Micro Starter Lite and RSLINX software are included. They can only be used to program Allen Bradley Micrologix 1000 and Micrologix 1100 PLCs.
Training course preview:

Invest in your future! People with Allen Bradley software skills can earn over $100k per year!

Training course's topics:

Overview of Hardware and Software
- Software (RSLOGIX 500 and RSLINX).
- Communication cable.
- PLC Hardware.
- Connecting to a SLC500 PLC with RSLINX
- Add and configure an RSLINX driver
- Configuring a DF1 communication link.
- RSWHO Window
- Driver Window
Connecting to a PLC with RSLINX.
- Adding and configuring an RSLINX driver.
- Configuring a DF1 communication link.
- Auto-Config
- RSWHO window.
- Driver Window.
- Communication link verification.
RSLOGIX 500 Pro memory addressing convention.
- Output/Input memory address.
- Boolean memory address.
- Integer memory address.
- Data files
RSLOGIX 500 Pro User Interface Overview
- Project tree window.
- Controller Folder.
- Processor status file.
- Function files.
- I/O configuration file.
- Channel configuration file.
- Program files folder.
- Program files.
- Program files rename, delete, hide and verify.
- Data files folder.
- Binary data file.
- Output data file.
- Input data file.
- Symbol name.
- Force files folder.
- Input force file.
- Output force file.
- Custom data monitor folder.
- Custom graphical monitors folder.
- Trend folder.
- Database folder.
- Ladder view window.
- The online bar.
- The instruction bar.
- The menu bar.
- The tool bar.
- The result pane.
Creating and configuring an RSLOGIX 500 Pro Project
- Creating a new project.
- Selecting the target PLC.
- Selecting an RSLINX communication driver.
- Configuring the PLC’s communication port.
- Indentify and configure PLC’s modules.
- Automaticall:+86-0535-6849126
